Icom IC-F320 [4/20] I front panel
![Icom IC-F310 [4/20] I front panel](/views2/1074525/page4/bg4.png)
1
1
PANEL DESCRIPTION
■ Front panel
TX / RX
4321
S
r MICROPHONE
CONNECTOR
(p. 2)
PROGRAMMABLE
FUNCTION KEYS [P0],[P1],[P2],[P3]
(p. 3)
e POWER SWITCH
(p. 2)
FUNCTION LED
(p. 2)
w CH UP/DOWN KEYS []/[] (p. 3)
q VOLUME UP/DOWN KEYS
(p. 2)
