OPTIONAL SmarTrunk II™ OPERATION
4
13
■ SmarTrunk II™ and
conventional modes
This transceiver meets to SmarTrunk II™ functions.
The optional UT-105 allows communication in conventional
channels or SmarTrunk II™ channels. Select a channel bank
for SmarTrunk II™ before trunking operation.
•Push [
BK UP
] or [
BK DN
] one or more times to select a chan-
nel bank for conventional channels or SmarTrunk II™ chan-
nels.
• Pushing [
CH UP
] or [
CH DN
] while pushing [
BK S
] can also select
the channel bank.
• Scanning starts when a channel bank for SmarTrunk II™ is se-
lected.
• Contact your dealer for channel bank details.
NOTE: Connect an optional DTMF microphone. Contact
your dealer for details.
■ SmarTrunk II™ operation
These features are enabled by a dealer or system operator
and may not be available in your system. Contact your dealer
for details.
D Placing a telephone call
Enter the phone number followed by [1], [M].
• A high-pitched beep indicates that the number is accepted.
• When the called party answers, push the [PTT] switch to talk, and
release it to listen.
D Calling another local system subscriber
Enter the subscriber number followed by [3], [M].
• A high-pitched beep indicates that the number is accepted.
• You hear ringing, then two short beeps when the subscriber an-
swers.
• If the other subscriber is on another call or out of range, you hear a
fast busy signal and the call terminates automatically.
D Receiving a call
When you hear ringing, push [M] to answer.
• For a group call, you hear a short ring followed by two short beeps.
You do not have to answer a group call to hear it over the air.
