Front Panel Storage
12
Indicator Status
* B4가 오프 위치에 있으면 HDD/SSD 업로드 기능이 정지합니다. 이때 전면의 LED 램프는 파란색만 켜지고 전원만 들어와
있음을 의미합니다. 깜빡이는 업로드 신호는 없습니다.
*전원을 켤 때 A2 LED에 파란색 불이 들어 옵니다.
LED
상태
색깔
깜빡임
HDD 설치
파란색
x
HDD액세스
보라색
o
B4 DISABLE
A2
파란색
x
B1 B2 B3 B4
A2A1 A3
FS304-12G
* When turning B4 switch to DISABLE position, the LED indication for HDD accessing will not work. In this case, the front LED
is displayed in solid blue only and that means it is with the power ON function only but without blinking accessing signal.
* A2 LED is shown BLUE when the power is in.
LED
State
Color
Blink
HDD in
Blue
x
HDD Access
Purple
o
B4 DISABLE
A2
Blue
x
*Beim Einstellen des B4-Schalters auf die DISABLE-Position funktioniert die LED-Anzeige für Festplattenzugriff nicht. Bei diesem
Zeitpnkt vorne zeigt die LED-Anzeige nur blau, es bedeutet , aber die Signale blinken nicht lesen.
* Beim Einschalten des Stroms, A2 LEDzeigt blau.
LED
Status
Farbe
Blinken
HDDeinfügen
blau
x
HDD Zugriffen
lila
o
B4 Deaktivieren
A2
blau
x
*เมื่อหมุนสวิตช์ B3 ไปที่ตำแหน่ง ปิดใช้งาน, ไฟแสดงสถานะ LED สำหรับการเข้าถึง HDD จะไม่ทำงาน ในกรณีนี้ด้านหน้าของจอ LED
จะแสดงผลเป็นสีน้ำเงินวาววับ เแสดงให้เห็นมีไฟ แต่ไม่มีไฟกระพริบที่เป็นสัญญาณการอ่าน
* เมื่อปิดสวิตซ์ไฟ A1 LED จะแสดงผลเป็นสีน้ำเงิน
LED
ลักษณะ
สี
ไฟกระพริบ
การวาง
น้ำเงิน
x
แสดงผล
ม่วง
o
B4 ปิดใช้งาน
A2
น้ำเงิน
x
