Product Overview

Front Panel Storage

1

Specifications

To accommodate PC user’s need for more storage flexibility and convenience, SilverStone created a line of front bay storage products

called the FS series. These are 5.25” bay chassis designed to fit 3.5” or 2.5” SAS-12G /SATA-6Gbit/s drives. Equipped with release

handle made out of finely brushed aluminum, hot-swapping drives is extremely quick and comfortable. Built-in cooling fan behind the

chassis ensures drive and run cool for extended life while individual LED indicators let user easily monitor drive status in one glance.

For security, each drive tray also has metal key lock. For those that need to upgrade their current PC with more drives, SilverStone’s

Drive support

Transfer rate

Host interface

Power connector

Drive door security

Number of Key

LED indicator

Cooling fan

Switch button

Net weight

Up to 12 Gbit/s (dependent on drive speed)

7-Pin SATA connector X3 or SAS primary channel connection (FS303-12G)

7-Pin SATA connector X4 or SAS primary channel connection (FS304-12G)

7-Pin SATA connector X5 or SAS primary channel connection (FS305-12G)

SATA 15-Pin X2

Triangle metal key lock design

2

Power ON : Blue

Accessing : Purple blinking

70mm fan x 1, 3000rpm (FS303-12G)

High/Low

ON/OFF

Introduction

Fits 3.5" SAS-12G/SATA-6Gbit/s drives in 5.25" device bay

Adjustable drive status LED and fan control system

Trayless & screwless design

Individual metal key lock for each drive for extra security

All aluminum body with beautiful hairline brushed finish

Independent drive status LED

Built-in cooling fan for excellent heat dissipation
