Product Overview
Specification
The SilverStone FP510 is an expertly engineered device that converts a
5.25" drive bay into 2.5" and 3.5" hot-swap bays. It has individual power
switches and LED indicators for both drive bays so user can turn on/off
drives as needed to save power and monitor their status. For extra
security, both 2.5" and 3.5" drive bays have integrated locks to prevent
accidental drive removal. In addition to housing drives, the FP510 also
has a pair of USB 3.1 Gen 1 ports (connected via internal USB 3 19pin)
for even more storage expansion and USB device accessibility.
Model No.
Color
Material
Form factor
Drive support
Data transfer rate
Host interface
Power connector
USB connector
LED indicator
Operating system support
Net Weight
Dimension
SST-FP510
Black
Plastic, Metal
5.25" drive bay
2.5" SATA drive x 1 (up to 9.5mm)
3.5" SATA drive x 1 (up to 25.4mm)
USB 3.1 Gen 1 up to 5Gbps (Compatible with USB 3.0/USB 2.0 / 1.1)
SATA I/II/III up to 6Gbps
7pin SATA connector x 2
15pin SATA power connector x 2
USB 3.1 Gen 1 Type-A x 2
Solid Blue: Powered
Blinking Red: Reading / writing
Microsoft Windows 10/8.1/8/7/XP/Vista or future release versions, Linux Kernel 2.4+ or above , Mac OS X
640 g
146 mm (W) x 42 mm (H) x 192 mm (L)
5.75" (W) x 1.65" (H) x 7.56" (L)
Introduction
Support one 2.5" and one 3.5" HDD/SSD in one 5.25" drive bay
Individual metal key lock for each drive for extra security
Dual USB 3.1 Gen 1 Super Speed 5Gbps interface on front panel
Adjustable ON/OFF power switches with drive status LED
Tray-less & screw-less design
Fully supports SATA hot-swap function
Special Features
1
FP510
Bay Devices
