Front Panel Storage
16
Indicator Status
FS204
*當B4開關切為OFF位置時，HDD讀取信號閃爍指示燈將關閉，LED在將電源開啟的狀態下顯示為藍燈恆亮。
*當B4開關切為OFF位置時，HDD讀取信號閃爍指示燈將關閉，LED在將電源開啟的狀態下顯示為藍燈恆亮。
*當B4開關切為OFF位置時，HDD讀取信號閃爍指示燈將關閉，LED在將電源開啟的狀態下顯示為藍燈恆亮。
LED
狀態
顏色
閃爍
HDD 置入
藍
x
HDD 存取
紫
o
B4 關閉
A1
過熱
紅
o
風扇故障
紅
o
藍
x
FS208
LED
狀態
顏色
閃爍
HDD 置入
藍
x
HDD 存取
紫
o
B4 關閉
A1 A3 A4
過熱
紅
o
風扇故障
紅
o
藍
x
FS212
LED
狀態
顏色
閃爍
HDD 置入
藍
x
HDD 存取
紫
o
B4 關閉
A1 A3 A4
過熱
紅
o
風扇故障
紅
o
藍
x
註: 插入托盤時，請對準溝槽，勿傾斜角度擺放
