Front Panel Storage
17
Indicator Status
FS204
*当B4开关切为OFF位置时，HDD读取信号闪烁指示灯将关闭，LED在将电源开启的状态下显示为蓝灯恒亮。
*当B4开关切为OFF位置时，HDD读取信号闪烁指示灯将关闭，LED在将电源开启的状态下显示为蓝灯恒亮。
*当B4开关切为OFF位置时，HDD读取信号闪烁指示灯将关闭，LED在将电源开启的状态下显示为蓝灯恒亮。
LED
状态
颜色
闪烁
HDD 置入
蓝
x
HDD 存取
紫
o
B4 关闭
A1
过热
红
o
风扇故障
红
o
蓝
x
FS208
LED
状态
颜色
闪烁
HDD 置入
蓝
x
HDD 存取
紫
o
B4 关闭
A1 A3 A4
过热
红
o
风扇故障
红
o
蓝
x
FS212
LED
状态
颜色
闪烁
HDD 置入
蓝
x
HDD 存取
紫
o
B4 关闭
A1 A3 A4
过热
红
o
风扇故障
红
o
蓝
x
注: 插入托盘时，请对准沟槽，勿倾斜角度摆放
