5
2
PANEL DESCRIPTION
u BATTERY INDICATOR
Indicates remaining battery power.
i LOCK INDICATOR (p. 10)
Appears while the lock function is activated.
o SUB CHANNEL READOUT
•Indicates channel 16 during priority scan. (p. 13)
•Indicates channel 16 during dualwatch or tri-watch.
(p. 14)
!0 DUPLEX INDICATOR
Appears when a duplex channel is selected.
!1 SCRAMBLER INDICATOR
Appears when the optional voice scrambler is activated.
(p. 10)
!2 DUALWATCH/TRI-WATCH INDICATORS (p. 14)
•“DUAL” blinks during dualwatch.
•“TRI” blinks during tri-watch.
!3 WEATHER CHANNEL/WEATHER ALERT INDICATOR
(p. 8)
•“WX” appears when weather channel group is selected.
•“ALT” appears while the weather alert function is acti-
vated; blinks when alert tone is received.
!4 LOW POWER INDICATOR (p. 9)
•Appears when low power is selected.
•Blinks when extra low power is selected.
!5 CALL CHANNEL INDICATOR (p. 7)
Appears when a call channel is selected.
!6 TAG CHANNEL INDICATOR (p. 13)
Appears when a tag channel is selected.
Indication
Battery level
Full
Middle
Charging
required
No
battery
