Icom IC-M59 [26/36] Connections and maintenance
![Icom IC-M59 [26/36] Connections and maintenance](/views2/1074641/page26/bg1a.png)
CONNECTIONS AND MAINTENANCE
6
22
■ Unpacking
q Mounting bracket ............................................................ 1
w DC power cable (OPC-632) ........................................... 1
e Microphone hanger (OPC-562) ...................................... 1
r Mounting bracket knobs ................................................. 4
t Mounting screws (5 x 20) ............................................... 4
y Mic hanger screws (3.5 x 30) ......................................... 2
u Flat washers (M4) ........................................................... 2
i Sticker (for scrambler function)* ..................................... 1
* Attach the sticker on the top side of the front panel when the UT-79
is installed.
■ Additional requirements
D FOR GENERAL OPERATION
• Marine VHF antenna
• Coaxial cable
D FOR DSC OPERATION
• UX-120
DSC UNIT
D FOR ENHANCED DSC OPERATION
• GPS receiver with NMEA0183 output for sending posi-
tioning and time data with a distress call
D FOR VOICE SCRAMBLER OPERATION
• UT-79
VOICE SCRAMBLER UNIT
Consult with your dealer if you need this function—dis-
assembly and soldering of the transceiver are required
for installation.
➀➂
➁➃
➄
➅
➆
➇
VOICE SCRAMBLER
