Candy C1 105-14S [15/17] Electricity supply and safety advice
![Candy C1 105-14S [15/17] Electricity supply and safety advice](/views2/1746424/page15/bgf.png)
Note: it is advisable to turn off the tap after each wash
to isolate the washing machine from the water supply.
For the washing machine to function properly the terminal end of the discharge hose (mouth)
must be at a minimum of 50 cm and a maximum of 85 cm from the ground.
Electricity supply and safety advice
Washing machines are supplied to operate at a voltage of 230V, 50 Hz single-phase. Check
that the conductor is powerful enough to supply at least 3.0 kW, then connect the plug to a 16A
earthed socket.
After installation,the appliance must be positioned so that the plug is accessible.
Check that the electricity supply to your home has an earthing system.
The socket in your home and the plug on the appliance must be of the same type.
It is generally not advisable to use multiple adapters and/or extension leads.
All Candy washing machines comply with the safety requirements laid down by the Quality
Trademark Institute.
29
Note: we recommend you keep the transit bracket,
braces and screws to immobilise the machine for future
transit.
The Manufacturers will not be responsible for any
possible damage to the machine caused by not
following the rules relating to releasing the mechanism.
The user is responsible for all costs of installation.
Water connection
The appliance must be connected to the water mains using new
hose-sets.
The old hose-sets should not be re-used.
The machine has an inlet hose with 3/4" B.S.P threaded end
connection to attach between the threaded connector on the
appliance and the cold water supply.
28
min 50 cm
max 85 cm
+2,6 mt max
max 100 cm
min 4 cm
