Candy CS 105 TXT-RU [35/37] Customer service installation

Installation

After removing the machine from the packaging, proceed

as follows:

On the back of the machine

1) Unscrew the centre brace A, the two side screws C

and remove the transverse bracket D and the relevant

plastic spacer.

2) Unscrew the 2 B braces and remove them. This will

cause 2 plastic spacers to fall into the machine.

3) Tilt the machine forward and remove the above-

mentioned plastic spacers.

4) Cover the holes using the caps enclosed

in the instructions envelope.

5) Fix the sheet of corrugated material on the

bottom as shown in picture.

6) Level the machine using the two adjustable rear feet.

ACD

Appliance complies with European Directive 89/336/EEC, 73/23/EEC and subsequent

amendments.

Technical data

■

Max. load of dry laundry

■

Water pressure

Measurements

■

Width

■

Depth

■

Height

NB: For specifications regarding electrical data, see the data panel on the front of the washing

machine (porthole area).

5 kg

(0,5 ÷ 10 bar)

0,05 ÷ 1 MPa

60 cm

40 cm

85 cm

Customer Service

The appliance is covered by a certificate of guarantee which allows you free use of the Candy

Technical Support Service. Remember to send off the guarantee certificate for validation

within 10 days of the date of purchase.

You should retain the receipt issued by the retailer when you purchased the machine to show

to the call out engineer, should you need to consult one.

If your washing machine shows signs of a defect or is not working properly, before you contact

GIAS Service we recommend you carry out the checks detailed on page 66 within the Trouble

shooting section.

If the problem with the machine persists after completing all the recommended checks, please

dial the GIAS Service number on the rear cover of this manual.

For the cost of a telephone call, you will be connected directly to GIAS. It is important you tell

the GIAS advisor your product’s model number and serial number, which you will find on the

rating label (16 characters, beginning with the number 3), found on the front of the washing

machine (door area). By doing this, your enquiry will be responded to more efficiently.

Fig. 2

Note: we recommend you keep the transverse bracket,

braces and screws to immobilise the machine for future

transit. The Manufacturers will not be responsible for any

possible damage to the machine caused by not

following the rules relating to releasing the mechanism.

The user is responsible for all costs of installation.
