TV FREQUENCY TABLE
■ China channels
CH Video Audio
1 49.75 56.25
2 57.75 64.25
3 65.75 72.25
4 77.25 83.75
5 85.25 91.75
6 168.25 174.75
7 176.25 182.75
8 184.25 190.75
9 192.25 198.75
10 200.25 206.75
11 208.25 214.75
12 216.25 222.75
13 471.25 477.75
14 479.25 485.75
15 487.25 493.75
16 495.25 501.75
17 503.25 509.75
18 511.25 517.75
19 519.25 525.75
20 527.25 533.75
21 535.25 541.75
22 543.25 549.75
23 551.25 557.75
24 559.25 565.75
25 607.25 613.75
26 615.25 621.75
27 623.25 629.75
CH Video Audio
28 631.25 637.75
29 639.25 645.75
30 647.25 653.75
31 655.25 661.75
32 663.25 669.75
33 671.25 677.75
34 679.25 685.75
35 687.25 693.75
36 695.25 701.75
37 703.25 709.75
38 711.25 717.75
39 719.25 725.75
40 727.25 733.75
41 735.25 741.75
42 743.25 749.75
43 751.25 757.75
44 759.25 765.75
45 767.25 773.75
46 775.25 781.75
47 783.25 789.75
48 791.25 797.75
49 799.25 805.75
50 807.25 813.75
51 815.25 821.75
52 823.25 829.75
53 831.25 837.75
54 839.25 845.75
CH Video Audio
55 847.25 853.75
56 855.25 861.75
57 863.25 869.75
58 871.25 877.75
59 879.25 885.75
60 887.25 893.75
61 895.25 901.75
62 903.25 909.75
63 911.25 917.75
64 919.25 925.75
65 927.25 933.75
66 935.25 941.75
67 943.25 949.75
68 951.25 957.75
■ Indonesian channels
CH Video Audio
2 48.25 53.75
3 55.25 60.75
4 62.25 67.75
5 175.25 180.75
6 182.25 187.75
7 189.25 194.75
8 196.25 201.75
9 203.25 208.75
10 210.25 215.75
11 217.25 222.75
12 224.25 229.75
21 471.25 476.75
22 479.25 484.75
23 487.25 492.75
24 495.25 500.75
25 503.25 508.75
26 511.25 516.75
27 519.25 524.75
28 527.25 532.75
29 535.25 540.75
30 543.25 548.75
31 551.25 556.75
32 559.25 564.75
33 567.25 572.75
34 575.25 580.75
35 583.25 588.75
36 591.25 596.75
CH Video Audio
37 599.25 604.75
38 607.25 612.75
39 615.25 620.75
40 623.25 628.75
41 631.25 636.75
42 639.25 644.75
43 647.25 652.75
44 655.25 660.75
45 663.25 668.75
46 671.25 676.75
47 679.25 684.75
48 687.25 692.75
49 695.25 700.75
50 703.25 708.75
51 711.25 716.75
52 719.25 724.75
53 727.25 732.75
54 735.25 740.75
55 743.25 748.75
56 751.25 756.75
57 759.25 764.75
58 767.25 772.75
59 775.25 780.75
60 783.25 788.75
61 791.25 796.75
62 799.25 804.75
63 807.25 812.75
