TV FREQUENCY TABLE
■ FOT channels
CH Video Audio
4 175.25 181.75
5 183.25 189.75
6 191.25 197.75
7 199.25 205.75
8 207.25 213.75
9 215.25 221.75
CH Video Audio
64 815.25 820.75
65 823.25 828.75
66 831.25 836.75
67 839.25 844.75
68 847.25 852.75
69 855.25 860.75
■ Italian channels
CH Video Audio
A* 53.75 59.25
B* 62.25 67.75
C* 82.25 87.75
D* 175.25 180.75
E* 183.25 188.75
F* 192.25 197.75
G* 201.25 206.75
H* 210.25 215.75
H1* 217.25 222.75
H2* 224.25 229.75
21 471.25 476.75
22 479.25 484.75
23 487.25 492.75
24 495.25 500.75
25 503.25 508.75
26 511.25 516.75
27 519.25 524.75
28 527.25 532.75
29 535.25 540.75
30 543.25 548.75
31 551.25 556.75
32 559.25 564.75
33 567.25 572.75
34 575.25 580.75
35 583.25 588.75
36 591.25 596.75
37 599.25 604.75
CH Video Audio
38 607.25 612.75
39 615.25 620.75
40 623.25 628.75
41 631.25 636.75
42 639.25 644.75
43 647.25 652.75
44 655.25 660.75
45 663.25 668.75
46 671.25 676.75
47 679.25 684.75
48 687.25 692.75
49 695.25 700.75
50 703.25 708.75
51 711.25 716.75
52 719.25 724.75
53 727.25 732.75
54 735.25 740.75
55 743.25 748.75
56 751.25 756.75
57 759.25 764.75
58 767.25 772.75
59 775.25 780.75
60 783.25 788.75
61 791.25 796.75
62 799.25 804.75
63 807.25 812.75
64 815.25 820.75
CH Video Audio
65 823.25 828.75
66 831.25 836.75
67 839.25 844.75
68 847.25 852.75
69 855.25 860.75
NOTE:
*In the case of the IC-R3,
‘A’–‘H,’‘H1’ and ‘H2’
channels are displayed
as ‘1’–‘8,’‘9’ and ‘10,’ re-
spectively.
