Icom IC-R10 [23/84] Set band scope function

BASIC OPERATION

Set band scope function

q While pushing [FUNC], push [(1)BSCOPE].

Repeat the above step or push [CLR] to turn OFF the band

scope function.

VFO

144.0000

higher freq.

displayed freq.

lower freq.

signal

strength
