НАСТРОЙКА ЖЕЛАЕМОЙ ЧАСТОТЫ
РУЧНАЯ НАСТРОЙКА: Нажмите на кнопку TUNING CD SKIP/SEARCH несколько раз до
тех пор, пока на дисплее не покажется желаемая частота.
АВТОМАТИЧЕСКАЯ НАСТРОЙКА: Нажмите и удерживайте кнопку TUNING CD
SKIP/SEARCH до тех пор, пока не начнется автоматический поиск передающих
станций, затем отпустите кнопку. Настройка будет автоматически останавливаться,
как только поймает сильный сигнал. Нажимайте на кнопку TUNING CD SKIP/SEARCH
до тех пор, пока не найдете желаемую частоту.
ВРЕМЕННОЕ ОТКЛЮЧЕНИЕ ЗВУКА
Для временного отключения звука нажмите кнопку “MUTE” на пульте дистанционного
управления. При этом на дисплее загорится индикатор отключения звука. Нажмите
“MUTE” снова, чтобы включить звук. При этом индикатор исчезнет с дисплея.
ПРОГРАММИРОВАНИЕ РАДИОСТАНЦИЙ
Вы можете запрограммировать до 10 радиостанций на частотах FM и AM.
1. Нажмите на кнопку POWER, чтобы включить магнитолу.
2. Нажимайте на функциональный переключатель до тех пор, пока на дисплее не
появится "TUNER". Выберите желаемый диапазон c помощью кнопки BAND/CD STOP
(!).
3. Найдите нужную передающую станцию, нажимая на кнопку TUNING CD
SKIP/SEARCH .
4. Нажмите на кнопку MEMORY/CLOCK SET. Затем в течение примерно 9 секунд
нажмите и удерживайте кнопку REPEAT/MEMORY UP до тех пор, пока на дисплее не
отразится желательный номер запрограммированной радиостанции.
5. Для занесения выбранной станции в память, нажмите на кнопку MEMORY/CLOCK
SET снова.
6. Если вы желаете запрограммировать несколько станций, повторите шаги 3Z5.
ПРИМЕЧАНИЕ: При отключении магнитолы из розетки, запрограммированные
радиостанции удаляются из памяти.
ВОСПРОИЗВЕДЕНИЕ ЗАПРОГРАММИРОВАННОЙ РАДИОСТАНЦИИ
1. Повторите шаги 1Z2 предыдущего раздела.
2. Для воспроизведения запрограммированной радиостанции нажмите кнопку
REPEAT/MEMORY UP.
3. Отрегулируйте звук и низкие частоты по вашему желанию.
ВОСПРОИЗВЕДЕНИЕ КОМПАКТДИСКА
• Установите режим "КомпактZдиск" (“CD“) при помощи функционального
переключателя. При этом на дисплее появится следующее: “00:00 00”.
• Откройте отсек для компактZдиска с помощью кнопки CD DOOR OPEN/CLOSE.
• Загрузите компактZдиск в отсек и закройте его. Дисплей высветит общее
количество дорожек и продолжительность воспроизведения диска.
• Нажмите кнопку "CD PLAY/PAUSE". Воспроизведение начнется только после
РУССКИЙ
13
RECALLING RADIO PRESETS
1. Follow steps 1 and 2 above.
2. Press the REPEAT/ MEMORY UP button to select a preset; the station will autoZ
matically be tuned in.
3. Adjust the BASS BOOST button and VOLUME control to as desired.
PLAYING COMPACT DISCS
NORMAL PLAYBACK
• Press the FUNCTION button to select CD (“00:00 00” will appear in the display).
• Press OPEN/CLOSE to open CD door then load a disc.
• The CD player will read the table of contens on the disc and the total number of
tracks and total playing time on the disc will appear in the display.
• Press PLAY % button to play CD ( press PAUSE " for Pause CD playing).
• Press SKIP ($/#) to select and search track. The LCD Track Display will show
the number of the selected track.
• Adjust the BASS BOOST button and VOLUME control to as desired.
• Press BAND/CD STOP ! button to stop playing CD.
FORWARD/REVERSE SKIP TRACK AND HIGHSPEED MUSIC SEARCH
1. During playback, press the CD Skip/Search ($) button once to advance the playZ
er to the beginning of the next track. Press the CD Skip/Search ($) button repeatZ
edly to advance the player to higher number tracks.
2. During playback, press the CD Skip/Search (#) button once to move the player
back to the beginning of the current track. Press the CD Skip/Search (#) button
repeatedly to move the playerback to lower numbered tracks.
3. During playback, depress and hold either the CD Skip/Search ($) or (#) button
to move the player forward or backward within a track to locate a specific musical
passage. The player will move forward or backward at high speed as long as the
button is depressed. When you release the CD Skip/Search ($) or (#) button,
normal playback will resume at the point.
REPEAT PLAYBACK
The single track or the whole disc can be repeated as many times as you like.
Press once the REPEAT/MEMORY UP button; ”REPEAT” will blink in the display. Press
SKIP ($/#) to select and search track. Press PLAY % button to play CD.
To REPEAT ALL of the tracks on a disc continuously, press the REPEAT/MEMORY UP
button twice. ”REPEAT” will blink in the display. Press PLAY % button to play CD. To
cancel Repeat Playback, press the REPEAT/MEMORY UP button until ”REPEAT” disZ
appears from the display or press BAND/CD STOP ! button.
PROGRAMMED PLAYBACK
The CD player in this unit has a 20 track programmable memory that allows you to
program up to 20 tracks on any disc for playback in any desired order. You may proZ
gram 20 different tracks or you may also program certain tracks to play more than
once. To perform programmed playback, proceed as follows:
8
ENGLISH
3477.qxd 13.06.02 18:57 Page 16
