GB
29
Removing and fitting the oven door:
1.Open the door
2.Make the hinge clamps of the oven door rotate
backwards completely (see photo)
3.Close the door until the clamps stop (the door will
remain open for 40° approx.) (see photo)
40°
4.Press the two buttons on the upper profile and
extract the profile (see photo)
5.Remove the glass sheet and do the cleaning as
indicated in chapter: "Care and maintenance".
6.Replace the glass.
WARNING! Oven must not be operated with inner
door glass removed!
WARNING! When reassembling the inner door
glass insert the glass panel correctly so that the
text written on the panel is not reversed and
can be easily legible.
7.Replace the profile, a click will indicate that the
part is positioned correctly.
8.Open the door completely.
9.Close the supports (see photo).
10.Now the door can be completely closed and the
oven can be started for normal use.
Automatic cleaning using the Diamond Clean
cycle
The Diamond Clean mode is an automatic cleaning cycle
which releases steam inside the cavity and uses the exclusi-
ve Diamond Clean enamel to make it easy to remove any dirt
residues from the cavity and accessories. Available in three
different levels: Economy, Normal and Intensive - to be used
based on the type of dirt.
The Diamond Clean cycle can be used to keep the oven al-
ways clean. During the cleaning process steam is released
inside the cavity which, together with the titanium-based Dia-
mond Clean enamel (on the inside walls of the oven and drip-
ping pans), makes it easy to clean the oven.
In order to start the Diamond Clean cycle:
1. Wait for the oven to cool down.
2. Place the dripping pan on level 1 and pour in the following
quantities of water: 150g for the Economy cycle, 250g for the
Normal cycle and 350g for the Intensive cycle. A smaller or
larger quantity of water than recommended may affect the
cycle results. Do not use detergents.
3. Close the oven door.
4. Turn the programmer knob to TRADITIONAL function, and
the thermostat knob to the temperature of 100’C
! To prevent any steam leaks do not open the door during the
cycle.
! In the last minutes of the intensive cycle the control panel
will partially and momentarily mist up. The mist will disappear
every time the tangential cooling fan is started.
*
2QO\DYDLODEOHLQFHUWDLQPRGHOV
- 150
- 250
- 350
-10
-15
-20
g
min
g
g
min
min
