Vitek VT-3476 [15/32] English

Vitek VT-3476 [15/32] English
4 Press the PLAY/PAUSE button (14).
5 Move the FUNCTION switch to CD.
6 Wait one hour.
The sound skips
1 The disc is severely damaged.
2 The device is being moved.
1 Change discs.
2 Stabilize the device.
TAPE RECORDER
Tape does not go in
Tape holder does not shut
The tape is upside down.
Put the tape right side up.
The tape will not play
1. The tape is defective.
2. The PAUSE button (4) is pressed.
3. The batteries are low.
4. The tape has grown slack.
1. Switch tapes.
2. Press the PAUSE button (4) again.
3. Replace them.
4. Use a pencil to take up the slack.
Cannot record
The tabs are removed on the tape.
Switch tapes.
Sound is distorted
Erasure is incomplete
• The heads are dirty.
• You are using a high position, or metal tape.
• Clean them.
• Use a normal tape.
RAIDIO
Too much static
• Receive electrical interference.
• Receiving interference from motors, fluorescent
lights or television.
• Plug in the power cord securely.
• Move the device to a different place.
• Turn off the TV.
• Adjust the antenna.
SPECIFICATION
CD Player
Sampling Frequency Pick-up
44.1 kHz Non-contact optical pick-up (Semi-
conductor laser)
Radio
Reception Frequency
FM: 88-108 MHz AM: 530-1600 kHz
MP3
File System Compatibility Sampling Frequency
Bit rates
ISO 9660 (level 1), Joliet 32 kHz, 44.1 kHz 32-
320 kbps
Tape Recorder
Track Motor Heads: 4-track 2-channel stereo
Electronic governor DC motor Magnetic head
for erasure, AC bias for recording
Fast-wind Time: Approx. sec. (C-60 cassette)
Microphone
Omnidirectional microphone
GENERAL
Speakers cm x 2 (4Q)
cm x 2 (8Q)
Max Output 2W + 2W(JEITA/DC)
Output Terminals: Phone jack (Stereo mini jack)
mW (Ohm)
Power Supply: AC 230 V~50Hz
DC 12 V(D-sizex8)
Power Consumption: 15 W
Dimension: 432 (W) x 157 (H) x 231 (D) mm
Technical characteristics may be changed by
the manufacturer without prior notice.
SERVICE LIFE – NO LESS THAN 5 YEARS
GUARANTEE
Details regarding guarantee conditions can be
obtained from the dealer from whom the appliance
was purchased. The bill of sale or receipt must be
produced when making any claim under the terms of
this guarantee.
This product conforms to the EMC-
Requirements as laid down by the Council
Directive 89/336/EEC and to the Low
Voltage Regulation (23/73 EEC)
ENGLISH
15
3476.qxd 01.04.2005 22:13 Page 15
