18
Avoid inadvertent starts by always unlocking the
switch when the plug is removed from the mains
socket or in case of a power cut.
Keep hands away from the rotating tool!
Remove chips and similar material only with the
machine at standstill.
Hold the power tool only at insulated housing
parts if there is any danger of making contact
with concealed electric cables or the supply
cable.
Contact with live wires energises the metal
parts of the housing and can cause electric shock
to the operator.
Caution must be exercised when driving screws
into hard materials (driving screws with metric or
imperial threads into steel)! The screw head may
break or a high reverse torque may build up.
The machine produces powerful forces when
seizing or catching the workpiece. Always hold the
machine firmly, adopt a steady stance and focus
on your work.
Secure small workpieces. For example, clamp in a
vice.
See page 3 (please unfold).
1 Chuck key (for geared chuck) *
2 Geared chuck *
3 Futuro Plus keyless chuck *
4Depth stop *
5
Additional handle *
6 Direction switch *
7 Sliding switch for normal drilling/impact
drilling *
8 Lock button (continuous operation)
9Trigger
10 Speed preselection wheel *
* depending on the features / model
Before plugging in, check to see that the
rated mains voltage and mains frequency,
as stated on the rating label, match with your
power supply.
SBE 561, SBE 521, BE 561:
Make sure the chuck clamps securely:
After drilling for the first time (clockwise), firmly
tighten the safety screw inside the chuck using a
screwdriver. Caution: left-handed thread! (see
Section 7.8)
6.1 Attaching the Additional Handle
(SBE 561, SBE 521, SB 561)
For safety reasons, always use the addi-
tional handle supplied.
Open the clamping ring by turning the additional
handle (5) anticlockwise. Push the additional
handle onto the collar of the machine. Insert the
depth stop (4). Securely tighten the additional
handle at the angle required for the application.
7.1 Adjusting the Depth Stop
(SBE 561, SBE 521, SB 561)
Loosen the additional handle (5). Set depth stop (4)
to the desired drilling depth and retighten addi-
tional handle.
7.2 Switching On and Off
To start the machine, press the trigger switch (9).
SBE 561, SBE 521, BE 561: Press in the trigger
switch to change the speed.
For continuous operation the trigger switch can be
locked using the lock button (8). To stop the
machine, press the trigger switch again.
In continuous operation, the machine
continues running if it is forced out of your
hands. Therefore, always hold the machine
with both hands using the handles provided,
stand in a safe position and concentrate.
7.3 Speed Preselection
(SBE 561, SBE 521, BE 561)
Select the (10) maximum speed using the prese-
lection wheel. See page 4 for recommended
drilling speeds.
7.4 Switching Between Normal Drilling/
Impact Drilling
(SBE 561, SBE 521, SB 561)
Select the desired operating mode by pushing the
sliding switch (7).
Drilling
Impact drilling
Work with high speed settings when impact
drilling.
Impact drilling and normal drilling only in a
clockwise direction.
5Overview
6 Commissioning
7Use
