ENGLISHen
8
7.1 Switching On and Off
To start the machine, press the trigger (4).
The speed can be changed by pressing in the
trigger.
For continuous operation, the trigger can be locked
with the lock button (5). To stop the machine, press
the trigger again.
In continuous operation, the machine
continues running if it is forced out of your
hands. Therefore, always hold the machine
with both hands using the handles provided,
stand in a safe position and concentrate.
7.2 Selecting the direction of rotation
Do not activate the rotation selector
switch (3) unless the motor has
completely stopped.
Selecting the direction of rotation:
R=clockwise
L = counter-clockwise
0=Central position: transport lock setting
(switch-on lock)
7.3 Tool Change with Geared Chuck
(1)
See illustrations A, page 2.
Opening the drill chuck: Open the geared chuck
with chuck key -1.
Clamping the tool: Insert tool -2- as far as possible
and, using the chuck key, evenly secure in all 3
bores -3.
7.4 Drill chuck with "Quick" change system
(for BE 75 Quick)
To remove: Push the interlock ring forward (a),
advance and pull off the chuck (b). (1)
To mount: (1) Push the interlock ring forward and
move the chuck as far as the limit stop on the drill
spindle.
If the trigger (4) cannot be depressed, check that
the direction of rotation selector switch (3) is fully set
to the R or L position.
Use only genuine Metabo accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating instruc-
tions.
Fit accessories securely. Secure the machine if it is
operated in a bracket. Loss of control can cause
personal injury.
For a complete range of accessories, see
www.metabo.com or the main catalogue.
Repairs to electrical tools must be carried out by
qualified electricians ONLY!
If you have Metabo electrical tools that require
repairs, please contact your Metabo service centre.
For addresses see www.metabo.com.
You can download spare parts lists from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: Never dispose of
power tools in your household waste! In
accordance with European Guideline 2002/
96/EC on used electronic and electric equipment
and its implementation in national legal systems,
used power tools must be collected separately and
handed in for environmentally compatible recycling.
Explanatory notes on the specifications on page 3.
Changes due to technological progress reserved.
P
1
=Rated input
P
2
=Power output
n
1
* =No-load speed
n
2
* =Load speed
max. dia. =Max. solid drill diameter
b =Chuck capacity
G=Spindle thread
m=Weight
D =D=Collar diameter
Measured values determined in conformity with
EN 60745.
Machine in protection class II
~ Alternating current
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
* Energy-rich, high-frequency interference can
cause fluctuations in speed. However, the fluctua-
tions disappear as soon as the interference fades
away.
Emission values
Using these values, you can estimate the
emissions from this power tool and compare these
with the values emitted by other power tools. The
actual values may be higher or lower, depending on
the particular application and the condition of the
tool or power tool. In estimating the values, you
should also include work breaks and periods of low
use. Based on the estimated emission values,
specify protective measures for the user - for
example, any organisational steps that must be put
in place.
Vibration total value
(vector sum of three directions)
determined in accordance with EN 60745:
7. Use
8. Troubleshooting
9. Accessories
10. Repairs
11. Environmental Protection
12. Technical Specifications
