![Toshiba 40L2453 [8/59] Connecting external equipment](/img/pdf.png)
Toshiba 40L2453 [8/59] Connecting external equipment
![Toshiba 40L2453 [8/59] Connecting external equipment](/views2/1075962/page8/bg8.png)
8
English
Connecting External Equipment
Before connecting any external equipment, turn off all main power switches. If there is no switch
remove the mains plug from the wall socket.
ILLUSTRATION SHOWS 32L24.
RGB/ PC
*a decoder could
be Digital Satellite or any
other compatible decoder.
*Model will determine
power cord position.
USB SOCKET
HDMI 1 INPUT
SOCKET
HDMI 2 INPUT
SOCKET
SCART 1
(INPUT/TV OUT)
POWER CORD
