Candy LB CTD 105 [10/14] Use of the selection controls
![Candy LB CTD 105 [10/14] Use of the selection controls](/views2/1761477/page10/bga.png)
26
A
. PROGRAMME/ TEMPERATURE SELECTOR
THIS CONTROL TURNS BOTH WAY
Use this control to select the desired wash programme/
temperature. Turn the control to bring the marker dot (p)
into line with the number or symbol of the desired
programme. Temperature selection depends on the
programme selected. The display shows the temperature
or the relevant readings for special programmes.
For programme selection, follow the programme table.
To
change settings or programmes when a programme
is under way, proceed as follows:
- Press Start/ Pause. The display will read (0 0 0).
- Select the new programme with the selector. The temperature of the programme selected
or the relevant indication for special programmes will appear.
- Press Start/ Pause again.
- The machine will run the new programme.
To
add more washing when the programme is under way, proceed as follows:
- Hold down Start/ Pause until the display shows three dashes (- - -).
- When the Door Secure lamp goes off, open the door and add more washing.
- Close the doors of the drum and the outer cover.
- Press Start/ Pause.
V
.DISPLAY: Delayed start, Spin speed, Temperature, Time remaining.
Display as per function indicated.
NOTE: Only lit buttons are enabled: if a button flashes the options it offers are not available
in the programme selected.
To change options when a programme is under way, proceed as follows:
- Press Start/ Pause until the display shows three dashes (---), then flashes the
temperature of the programme selected.
- Make the change desired (e.g. reduction of spin speed).
- Press Start/ Pause. The time remaining to the end of the programme will appear on the
display.
- The machine will resume the programme with the new setting.
USE OF THE SELECTION CONTROLS
