12
Adjusting the Air Flow Direction
You can adjust the air flow direction to increase your com-
fort.
■
To adjust the horizontal
blades (flaps)
1. Press “SWING button”.
The display will light up and the flaps will
begin to swing.
2. When the flaps have reached the
desired position, press “SWING
button” once more.
The display will go blank.
The flaps will stop moving.
C
TEMP
ON/OFF
POWERFUL
HOME LEAVE
MODE
TIMER
FAN
SWING
SILENT
SENSOR
ON
CANCEL
OFF
ON
1, 2
01_EN_3P098590-2L.fm Page 12 Thursday, July 28, 2005 4:55 PM
