Daikin FTKE35BVMA [19/32] Intelligent eye operation
![Daikin FTKE25BVMA [19/32] Intelligent eye operation](/views2/1761707/page19/bg13.png)
18
INTELLIGENT EYE Operation
“INTELLIGENT EYE” is the infrared sensor which
detects the human movement.
■
To start INTELLIGENT
EYE operation
1. Press “SENSOR button”.
■
To cancel the
INTELLIGENT EYE
operation
2. Press “SENSOR button” again.
[EX.]
C
TEMP
ON/OFF
POWERFUL
HOME LEAVE
MODE
TIMER
FAN
SWING
SILENT
SENSOR
ON
CANCEL
OFF
1, 2
When somebody in the room
• Normal operation
When nobody in the room
• 20 min. after, start
energy saving
operation
.
Somebody back in the room
• Back to normal operation.
01_EN_3P098590-2L.fm Page 18 Thursday, July 28, 2005 4:55 PM
