SiBE04-808_B Indoor Unit
Removal Procedure 160
5
When mounting the
front panel, make sure
that the shaft is fitted in
the guide before closing
the panel.
Caution on Mounting
When mounting the front
panel, fit the right and left
rotary shafts one by one into
the grooves and fully push
them in position.
Step Procedure Points
(R7908)
Shaft
