Daikin FTXS71GV1B [11/12] Sound data
![Daikin FTXS71GV1B [11/12] Sound data](/views2/1761743/page11/bgb.png)
• Split Sky Air • Indoor Units
9
• Indoor Units • R-410A • FTXS-GV1B
6 Sound data
6 - 1 Sound pressure spectrum
FTXS60GV
3D051227D
NOTES
1Over All (dB):
(B,G,N is already rectified)
2 Measuring place: measure in anechoic room.
3Operation noise differs with operation and ambient conditions.
4 Location of microphone.
JISC9612
The operation noise
measuring method is in
accordance with JISC9612
NOTES
1Over All (dB):
(B,G,N is already rectified)
2 Measuring place: measure in anechoic room.
3Operation noise differs with operation and ambient conditions.
4 Location of microphone.
JISC9612
The operation noise
measuring method is in
accordance with JISC9612
Octave band sound pressure level dB (0 dB = 0.0002μ bar)
Octave band sound pressure level dB (0 dB = 0.0002μ bar)
Octave band center frequency - IEC (Hz) Octave band center frequency - IEC (Hz)
Scale
50Hz
220-240V
(H) (L)
A45 36
Scale
50Hz
220-240V
HL
A44 35
Cooling Heating
Approximate
threshold hearing
for continuous
noise
Approximate
threshold hearing
for continuous
noise
1m 1m
0.8m
0.8m
FTXS71GV
3D051225D
NOTES
1Over All (dB):
(B,G,N is already rectified)
2 Measuring place: measure in anechoic room.
3Operation noise differs with operation and ambient conditions.
4 Location of microphone.
JISC9612
The operation noise
measuring method is in
accordance with JISC9612
NOTES
1Over All (dB):
(B,G,N is already rectified)
2 Measuring place: measure in anechoic room.
3Operation noise differs with operation and ambient conditions.
4 Location of microphone.
JISC9612
The operation noise
measuring method is in
accordance with JISC9612
Octave band sound pressure level dB (0 dB = 0.0002μ bar)
Octave band sound pressure level dB (0 dB = 0.0002μ bar)
Octave band center frequency - IEC (Hz) Octave band center frequency - IEC (Hz)
Scale
50Hz
220-240V
(H) (L)
A46 37
Scale
50Hz
220-240V
(H) (L)
A46 37
Cooling Heating
Approximate
threshold hearing
for continuous
noise
Approximate
threshold hearing
for continuous
noise
1m 1m
0.8m
0.8m
