![Candy HGSW 485DSW/1-S [12/32] Quick user guide](/views2/1762507/page12/bgc.png)
!
12
5. QUICK USER GUIDE
This washing machine automatically adjusts
the level of the water to the type and
quantity of washing. This system gives a
reduction in energy consumption and a
saving in washing times.
!
Turn on the washing machine and select
the required program.
!
Adjust the washing temperature if
necessary and press the required "option"
buttons.
!
Press the START/PAUSE button to start
washing.
!
At the end of the programme, the
message "End" will appear on the display
or, on some models, all wash stage
indicator lights will turn on.
!
Turn off the washing machine.
For any type of wash, see the program
table and follow the operating sequence
as indicated.
Water pressure:
min 0.05 Mpa / max 0.8 Mpa
(0.05 MPa dispenses approximately 1 litre
of water in 10 seconds)
Spin r.p.m.: See rating plate.
Power input / Power current fuse amp /
Supply voltage: See rating plate.
6. CONTROLS AND
PROGRAMS
A Programme selector with OFF
position
B START/PAUSE button
C DELAY START button
D DRYING SELECTION button
E RAPID / STAIN LEVEL button
F TEMPERATURE SELECTION
button
G SPIN SPEED button
F+G KEY LOCK
H Digital display
I DRYING SELECTION indicator
lights
L DOOR LOCKED indicator light
M KG DETECTOR indicator light
N KEY LOCK indicator light
O TEMPERATURE SELECTION
indicator lights
P SPIN SPEED indicator lights
Q SMART TOUCH area
Program selection
DRYING
If you would like the drying cycle to
begin automatically after washing,
select the programme required using
the DRYING SELECTION button.
Or you can finish the wash and then
select the drying programme and
load size.
Wait until the DOOR LOCKED light has
gone out before opening the door.
Technical data
A
DC E F G B
H
L
Q
I MNO P
