PD20 Series
- 30 -
Function
code
Description Set range Unit Default
Display
level
Modifi-
cation
level
Notes
F2.08
Upper limit
of running
frequency
F2.10~F2.09 Hz 50.00
1
●
The upper limit of SPD’s
running frequency
F2.09
Maximum
output
frequency
10.00~60.0 Hz 50.00
●
F2.10
Lower limit
of running
frequency
0.00~F2.08 Hz 0.00
●
F2.11
Options when
it reaches the
lower limit
frequency
0: Running
according to the
lower limit
frequency
1: stop
2: standby
\ 2
●
F2.12
Setting of
carrier
frequency
1.0~15.0 kHz
Set
accordin
g to the
machine
type
○
Noise of the motor can be
adjusted by modifying this
value
F2.13
Fan running
mode
0: Running
constantly when
power on
1: Automatically
running
\ 1
○
Fan is controlled by
temperature; automatically
running
F2.14
Selection of
the halt mode
0: Stop by
deceleration
1:Stop
automatically
\ 0
●
The selection for the halt
mode of SPD
