Candy LS CD 475 SX [6/21] Selecting the programme and special functions
![Candy LS CD 475 SX [6/21] Selecting the programme and special functions](/views2/1763720/page6/bg6.png)
The waterblock system has been designed to improve the
safety of your appliance, particularly when the machine is left
unattended.
The waterblock system actually prevents flooding which might
be caused by a machine malfunction or as a result of a
fracture on the pipes.
How does waterblock work
The sump located in the base of the appliance collects any
possible water leakage and operates a sensor which
subsequently activates a valve placed under the water tap and
stops any water from the supply even with the tap fully opened.
If the box containing the electrical parts is damaged, remove
the plug from the socket immediately.
To ensure perfect operation of the safety system, box “A” with
the hose should be connected to the tap as shown in Figure
“1”. The inlet hose should not be cut, as it contains parts under
load. If the hose is not long enough for correct connection, it
must be replaced with a longer one. The hose can be obtained
from your Service Agent.
A
Fig. 1
The waterblock system
Attention
This dishwasher is equipped with an anti-overflow safety device
which works even when power is switched off, and if the water
level is too high the supply will automatically be closed off.
Important
To ensure the correct operation of the anti-overflow safety
device, it is recommended not to move or to tilt the dishwasher
during operation.
If it is necessary to move or to tilt the dishwasher, first make
sure the washing cycle is finished and that no water is left in
the tank.
To set the programme, turn the dial clockwise until the pointer
( ) indicates the symbol of the required programme on the
control panel. Then press the On/Off button O/I. Ensure that
the water supply is turned on and the door is closed properly.
Half load button
By pressing this button it is possible to wash a small quantity
of crockery using only the upper basket for dishes and cutlery
in the bottom basket. This reduces water and energy
consumption and requires a smaller quantity of detergent as
well.
32’ BUTTON
The “32’ button” combined with the delicate programme
washes lightly soiled dishes in 32 minutes.
IMPORTANT:
When the 32’ button is selected, the programme finishes at the
“STOP 32’ ” position on the programme dial.
1
2
Selecting the programme and special functions
Use in conjunction with programme guide
10
11
32’
