• Ventilation • EKEQ
3
• Accessory • EKEQ
2 Specifications
Standard Accessories : Stopper (closing up); Quantity : 0;
Standard Accessories : Wire to wire splice; Quantity : 6;
Standard Accessories : Thermistor (R2T/R3T); Quantity : 2;
Standard Accessories : Capacity setting adapter; Quantity : 7;
Standard Accessories : Insulation sheet; Quantity : 2;
Standard Accessories : Rubber sheet; Quantity : 2;
Standard Accessories : Installation and operation manual; Quantity : 1;
Standard Accessories : Screw nut; Quantity : 8;
Standard Accessories : Tie-wraps; Quantity : 6;
Standard Accessories : Thermistor (R1T); Quantity : 1;
2-1 Technical Specifications EKEQDCB EKEQFCBA EKEQMCBA
Application Pair Multi
Outdoor unit ERQ VRV
Dimensions Unit Height mm 132
Width mm 400
Depth mm 200
Packed unit Height mm 215
Width mm 495
Depth mm 310
Weight Unit kg 3.6 3.9 3.6
Packed unit kg 4.6 4.9 4.6
Packing Material Carton / EPS / Plastic
Casing Colour White grey
Material Resin
Operation range Cooling Min. °CDB -10
Max. °CDB 40
On coil temperature Heating Min. °CDB -
Cooling Max. °CDB -
2-2 Electrical Specifications EKEQDCB EKEQFCBA EKEQMCBA
Power supply Name V3
Phase 1~
Frequency Hz 50
Voltage V 230
Voltage range Min. % -10
Max. % 10
