• Ventilation • EKEQ
5
• Accessory • EKEQ
3 Options
3 - 1 Options
EKEQ
Nr. Item EKEQFCBA EKEQDCB EKEQMCBA
1 Remote control / Wired type
BRC1D528 (*)
BRC1E52A(*)
BRC1E52B(*)
BRC2E52C(*)
BRC3E52C(*)
BRC1D528
BRC1E52A
BRC1E52B
BRC2E52C
BRC3E52C
2 Wiring adapter for electrical appendices / KRP4A516
3 Remote sensor / KRCS01-1
4 Valve kit
EKEXV50
EKEXV63
EKEXV80
EKEXV100
EKEXV125
EKEXV140
EKEXV200
EKEXV250
EKEXV400
EKEXV500
EKEXV63
EKEXV80
EKEXV100
EKEXV125
EKEXV140
EKEXV200
EKEXV250
EKEXV50
EKEXV63
EKEXV80
EKEXV100
EKEXV125
EKEXV140
EKEXV200
EKEXV250
EKEXV400
EKEXV500
(*) Useful accessory tool for service and installation, but not required for operation
CAUTION
1. The control boxes can be connected to the following DIII-NET devices: iTouch Manager II and Modbus Interface DIII.
2. 2QO\XVHWKLVV\VWHPLQFRPELQDWLRQZLWKD¿HOGVXSSOLHGDLUKDQGOLQJXQLW
Do not connect this system to other indoor units.
3. Refer to the combination table for the application of the valve kits.
4D090226
