AVerMedia AVerTV BoxW9 Plus
ENG-6
12.PC BGM/ Res.
- Switch the audio source from the AVerTV BoxW9 Plus when in PC
display mode
- Switch display resolution setting to 1024x768 when in TV/Video
mode
13.SOURCE
Switch between TV or external video sources
14.MUTE
To turn off /on the sound
15.PREVIEW
Display 13 consecutive TV channels on-screen
16.CH▲/▼
- Go to the next or pre-vious TV channel line up
- Use these buttons to make the selection in the menu or picture setting
- In adjusting the OSD position, use these buttons to move the menu
display up and down of the screen
17.SLEEP
To automatically turn off the unit after 30, 60, 90, 120 or 150 minutes.
18.TELETEXT
This function is not available for this product.
19.PIP SIZE
Set the PIP window size to 1/4, 1/9, or 1/16 of the screen when in PIP
mode..
20.4:3/16:10
Press to switch among various display aspect ratios in a widescreen
resolution (「4:3」 or 「PANORAMA」).
21.AV /PC
To toggle between TV/ Video or PC display
3.3 Customizing the Picture Setting
CONTRAST
SCREEN RESOLUTION
PIP SIZE
SATURATION
SHARPNESS
SET DEFAULT
HUE
BRIGHTNESS
10
10
10
10
10
If you want to change the screen resolution, set the PIP
SIZE, or adjust the picture quality, press the PICTURE
button on the remote control. Then, you can use the CH▲ or
CH▼ button to select the items in the PICTURE menu; and
the Vol◄ or Vol ► button to open a submenu or make picture
setting adjustments.
To restore the picture default settings, select SET DEFAULT
and then press Vol ►.
1360X768
SCREEN RESOLUTION
1024X768
1280X1024
1440X900
1680X1050
1920X1200
1600X1200
1280X768
In the SCREEN RESOLUTION submenu, choose the desired
display resolution for your monitor screen. Press the CH▲ or
CH▼ button to move up or down the menu and select a
resolution, then press Vol ► to confirm your selection. If you
don’t confirm the selected resolution by pressing Vol ►
within 15 seconds, the resolution will keep at previous
resolution.
PIP SIZE
1/4
1/9
1/16
In the PIP SIZE submenu, choose the appropriate PIP
window ratio. Press the CH▲ or CH▼ button to make a
selection, then press Vol ► to confirm your selection.
To adjust picture properties such as brightness, contrast,
saturation, hue, or sharpness, first press CH▲ or CH▼ to
select a property. Then, press Vol◄ to decrease its level or
press Vol ► to increase the level.
