FWP4
1 BEFORE STARTING THE INSTALLATION PROCEDURE
Carefully read this manual.
Installation and maintenance should be carried out by technical
personnel qualied for this type of machine, in compliance with
current safety regulations.
When receiving the unit please check its state verifying if any
damage occurred during the transport.
For installation and use of accessories, please refer to the relative
technical sheets.
Identify the model of the FWP fan coil following the indications
on the packing container.
SAFETY SYMBOLS
Carefully read this manual.
Warning
Use personal protective equipment
USE SUITABLE PPE (GLOVES FOR REFRIGERANT, PROTEC-
TIVE GOGGLES)
WARNING: Electrical and electronic products may not be
mixed with unsorted household waste. Do NOT try to dis-
mantle the system yourself: the dismantling of the system,
treatment of oil and of other parts must be done by an
authorized installer and must comply with applicable leg-
islation. Units must be treated at a specialized treatment
facility for reuse, recycling and recovery. By ensuring this
product is disposed of correctly, you will help to prevent
potential negative consequences for the environment and
human health. For more information, contact your installer
or local authority.
ATTENTION: the unit hasn't dangerous components ac-
cording to the classication of Regulation 1357/2014.
2 INTENDED USE
Daikin will not accept any liability for damage or injury caused as
a result of installation by non-qualied personnel; improper use
or use in conditions not allowed by the manufacturer; failure to
perform the maintenance prescribed in this manual; use of spare
parts other than original factory parts.
Equipment designed for ambient air conditioning and intended
for use in civil comfort applications.
INSTALLATION SITE
When choosing an installation site, you should observe the fol-
lowing rules:
Ū The air conditioning unit should not be placed immediately
under a socket
Ū Do not install the unit in places where inammable gases or
powders are present
Ū Do not expose the unit to sprays of water; do not install the
unit in laundry room
Ū Install the fan coil on walls or ceilings able to withstand its
weight. Keep a clear space all around the unit to assure the
proper functioning and accessibility for maintenance
Ū Store the unit in its packing container until you are ready to
install it to prevent dust from inltrating inside it.
3 UNIT DESCRIPTION
MODULATION AND EFFICIENCY IN A RECESS CEILING-MOUNTED UNIT
The range is completed by FWP, which uses inverter BLDC tech-
nology in the electric motors. To the features of FWP adds the
benets of brushless technology, including a reduction in elec-
tricity consumption and consequent reduction in CO
2
emissions,
increase in operating exibility thanks to the modulation of air
ow and increase in the level of comfort in terms of temperature,
humidity and noise levels.
The range is made up of 8 models with air ows from 300 to 1200
m³/h.
Continuous modulation of the air ow and the use of high-ef-
ciency heat exchangers enables operation also with small
air-water temperature dierences.
The heat exchangers can also be optimized in the circuit for cen-
tralized applications such as district cooling.
