1-5
ASUS LCD Monitor XG Series
1.4 Connect cables
1.4.1 Rear of the LCD monitor
4
HDMI-2 HDMI-1
DCIN
HDMI-3HDMI-4
8
12
1
2
3
4
5
9 10 11
6
7
12
1. Audio in
2. Earphone Jack
3. USB Downstream Port
4. USB Downstream Port
5. USB Upstream Port
6. HDMI-4 Port
7. HDMI-3 Port
8. HDMI-2 Port
9. HDMI-1 Port
10. DisplayPort
11. AURA SYNC Port
12. DC-IN Port
13. Kensington Lock
