3-6
Chapter 3: General Instruction
4. Image
You can adjust OD, Aspect Control, ASCR, Adaptive-Sync/FreeSync,
Blue Light Filter, HDR, Dynamic Dimming and Shadow Boost from
this main function.
GameVisual
Color
Input Select
System Setup
MyFavorite
PIP/PBP Setting
MOVE/ENTER
BACK
OD
Adaptive-Sync/FreeSync
Blue Light Filter
ASCR
Aspect Control
EXIT
GamePlus
+
HDR
Dynamic Dimming
Shadow Boost
HDMI-1 3840x2160@ 60Hz
Racing Mode Aura Color Cycle
ROG Strix XG43U HDR OFF
• OD: Speeds up the response time by Over Drive technology.
Including Level 0~Level 5.
• Aspect Control: Adjusts the aspect ratio to “Full” and “4:3”.
• ASCR: Select ON or OFF to enable or disable dynamic contrast
ratio function.
• Adaptive-Sync/FreeSync: It can allow a Adaptive-Sync/
FreeSync supported graphics source to dynamically adjust display
refresh rate based on typical content frame rates for power
efficient, virtually stutter free and low-latency display update.
FreeSync support 48-120Hz under DP mode.Adaptive support
FHD/QHD 48-120Hz under HDMI mode.
• Blue Light Filter: Adjust the energy level of blue light emitted
from LED backlight.
• HDR: High Dynamic Range. Contains three HDR modes (ASUS
Cinema HDR, ASUS Gaming HDR and FreeSync2 HDR). ASUS
Cinema HDR and ASUS Gaming HDR are selectable when input
video is not AMD FreeSync2 HDR. FreeSync2 HDR is selectable
when connected to AMD FreeSync2 HDR video. (FreeSync2 HDR
non-support under HDMI mode).
• Dynamic Dimming: Dynamic local dimming, turn on this feature
to improve the dynamic contrast.
• Shadow Boost: Dark color enhancement adjust monitor gamma
curve to enrich the dark tones in an image making dark scenes
and objects much easier be found.
