Green yellow cable E Ground or Black cable L1 Phase 1 Grey cable L2 Phase 2 Blue Brown cable N Neutral Green yellow cable E Ground Installing the product 1 Prepare the surface of the counter as shown in the figure 2 Turning the hob upside down place it on a flat surface 3 The sealing gasket provided in the package must be applied on the lower casing bend around the hob as shown in the figure during installation of the hob 4 Fix the mounting springs inserting and screwing them through the holes of the bottom case as shown In the figure min If the board is below It Is required to leave a ventilation opening of minimum 180 cm2 at the rear section of the furniture as illustrated in the following figure For some models your product may come with the mounting springs already fitted on it The number of mounting springs on your product varies depending on product Imodel 5 Place the hob on the counter and align it 6 When the hob is placed on the counter top it will be fixed easily with the help of the clamps If the installation with this clamps are not in appropriate for your cooktop additional 2 mounting clamps can be fixed to the front side of the product as shown in the below figure min During installation of your induction hob place the product parallel to the Installation surface Also apply sealing gasket to the parts of the hob contacting the counter as described below In order to prevent any liquid from penetrating between the product and the counter 11ÆN
