Entel HT786T [7/18] Optional accessories

Common

Antenna Options

CXW640 Antenna adapter for external aerial

CAT20 Helical antenna VHF

CAT80 Whip antenna UHF

CAT20S Stubby antenna VHF

CAT80S Stubby antenna UHF

Attaching / Removing the Battery Pack

1 To attach, locate the pegs on the bottom of

the battery and place into the slots on the

radio. Then press the top of the battery against

the radio. Secure battery by tightening the

screw clockwise by hand. (Do not over

tighten)

2 To remove, unscrew the locking screw

anticlockwise and pull the battery away from

the top of the radio.

Attaching / Removing the Belt Clip

1 To attach, press the clip into the slot on

the back of the battery and slide up until

you hear a “click”.

2 To remove, pull the tab (a) towards the

belt clip. Then slide the belt clip

downwards (b).

Optional Accessories cont...

For complete up to date list of optional

accessories visit www.entel.co.uk

Preparing Your Radio For Use

CHP1/750 Light weight single earpiece headset with in-line PTT & VOX*

CHP750HS Single earpiece ear defender headset with boom mic and in line PTT for hard hat & VOX*

CHP750HD Double earpiece defender headset with boom mic and in line PTT for hard hat & VOX*

CHP750D Double earpiece headband defender headset with boom mic and in line PTT & VOX*

CHP750BT Bluetooth double earpiece headband defender headset with boom mic and ear cup PTT

* VOX = Voice Operated Transmit (hands free operation)

CAT10S-78 78MHz compressed antenna

CAT10S-85 85MHz compressed antenna

CAT10S 66-88MHz uncut compressed antenna

Bluetooth option board in radio is required to use Bluetooth audio accessories.
