Entel HT942 [12/30] Functions

Functions

The Scan Function

Programming the Scan Function:

1. Select the desired channels to be scanned using the and buttons.

2. Press the [MEM] button to store the channel in the transceiver’s memory. [M] will be

displayed on the LCD if the channel is memorised and will be scanned.

3. To add further channels, repeat steps 1 and 2.

4. To delete a channel from the transceiver’s scan list, press the [MEM] button on a channel

that displays the [MEM] icon until the icon disappears.

5. All channels programmed remain in the transceiver’s scan memory, even if the power is

switched off.

Using the Scan Function:

Once a Scan list has been programmed, you can start scanning by pressing the [SCAN]

button. The scan proceeds from the lowest to the highest programmed channel number

and stops on channels when a transmission is received. The transceiver will display the

channel number and alias as it is being scanned.

To stop the scan at any time, press the [SCAN] key again.

VOX (Voice Operated Transmit)

In VOX mode the transceiver will react to your voice, and transmit automatically without you

having to press the PTT button when it receives audio above a selected level. There is always a

slight delay for the electronic switching and consideration will need to be given. To get optimum

performance from the VOX feature you should use a noise cancelling headset or earpiece

microphone (see accessory options).

Using the VOX Feature:

To use the VOX feature, assign it to a button using the Entel Programmer and a

programming lead. Press the assigned button to enable \ disable it. The VOX symbol will be

displayed on the LCD when the VOX is enabled.

Changing the Sensitivity of the VOX:

To control the sensitivity of the VOX assign the “VOX Level” to a button using the Entel

Programmer. Press the button to display the current level, then use the rotary control on top

of the radio to select the level you wish (the lower the level the lower the sensitivity). Then

press the PTT to select the level and return to normal radio operation.

HTX44
