Entel HT942 [16/30] Channel chart
![Entel HT942 [16/30] Channel chart](/views2/1076799/page16/bg10.png)
15
Channel Chart
HTX44
CH
Channel Set
S/D
Frequency
Channel Use
USA CAN INT
Receive Transmit
1A
X
S 156.05000
PORT OPERATION AND COMMERCIAL
1
X X
D 160.65000 156.05000
PUBLIC, PORT OPERATIONS
2
X X
D 160.70000 156.10000
PUBLIC, PORT OPERATIONS
3A
X
S 156.15000
US GOVERMENT, COAST GUARD
3
X X
D 160.75000 156.15000
PUBLIC, PORT OPERATIONS
4A
X
S 156.20000
COMMERCIAL FISHING
4
X
D 160.80000 156.20000
PUBLIC, PORT OPERATIONS
5A
X X
S 156.25000
PORT OPERATIONS, VTS IN SEATTLE
5
X
D 160.85000 156.25000
PUBLIC, PORT OPERATIONS
6
X X X
S 156.30000
INTER-SHIP SAFETY
7A
X X
S 156.35000
COMMERCIAL
7
X
D 160.95000 156.35000
PUBLIC, PORT OPERATIONS
8
X X X
S 156.40000
COMMERCIAL (INTER-SHIP ONLY)
9
X X X
S 156.45000
BOATER CALLING CHANNEL
10
X X X
S 156.50000
COMMERCIAL / INTERSHIP
11
X X X
S 156.55000
COMMERCIAL / PORT OPERATIONS
12
X X X
S 156.60000
PORT OPERATION
13
X X
S 156.65000
INTER-SHIP NAVIGATION SAFETY
13
X
S 156.65000
INTER-SHIP NAVIGATION SAFETY
14
X X X
S 156.70000 PORT OPERATION
15
X
R 156.75000 - SHIP MOVEMENT
15
X X
S 156.75000 SHIP MOVEMENT \ INTERSHIP
16
X X X
S 156.80000 INTERNATIONAL DISTRESS
17
X X X
S 156.85000 STATE CONTROLLED \ INTERSHIP
18A
X X
S 156.90000 COMMERCIAL
18
X
D 161.50000 156.90000 PORT OPERATION, SHIP MOVEMENT
19A
X X
S 156.95000 COAST GUARD
19
X
D 161.55000 156.95000 PORT OPERATION, SHIP MOVEMENT
20A
X
S 157.00000 PORT OPERATION
20
X X
D 161.60000 157.00000 PORT OPERATION AND SHIPMENT
20
X
D 161.60000 157.00000 PORT OPERATION AND SHIPMENT
21A
X X
S 157.05000 U.S. GOV, CANADIAN COST GUARD
21
X
D 161.65000 157.05000 PORT OPERATION, SHIP MOVEMENT
