ENG

Fixing the vitroceramic hob:

· Apply the one-sided self-adhesive sealing tape supplied all the way round the lower edge

· Screw the 4 worktop mounting brackets on the side walls of product.

· Place the hob into the opening on the worktop.

of the cooking surface along the outer edge of the glass ceramic panel. Do not stretch it.

Installation steps:

1.Place the hob into the opening on worktop. The size of opening is given in Figure A.

For details, see the heading Fixing the vitroceramic hob.

2.Connect the hob to the oven using the plug given on the hob. The socket for plug is

placed on the rear panel of oven.

3.Connect the oven to the electrical supply.

4.Place the oven into its built-in niche. Either placement in Figure A or placement in Figure B

is applicable depending on the size of cabinet opening. For details, see the heading Fixing

the oven.

worktop

mounting

bracket
