ENG

Insert the oven into cabinet partly by pushing it forward. Open the oven door and insert 4

screws into countersunk holes on the front frame. Locate the spacers behind the flange of

front frame and screw them till the surface of spacer touches the front frame. While doing

this, please pay attention that the chamfered edge of each spacer is faced to the rounded

edge of front frame. Push forward the product completely and finally screw it to wooden

part.

The dimensions and material of the cabinet in which the oven will be installed must be

correct and resistant to increases in temparature. In a correct installation, contact with

electrical or insulated parts must be pervented. Insulating parts need to be fitted in a way to

ensure that they cannot be removed by using any kind of tool. Installing the appliance in the

close vicinity of a refrigerator or a deep-freezer is not recommended. Otherwise, the

performance of the above-mentioned appliances will be negatively affected due to

emanating heat.

Warning regarding the installation of built-in oven without cooling fan

5mm5mm

Prior inserting the oven, it is necessary to remove the

rear kitchen element panel in the area of the oven

opening.

Equally, the front part of the element must have an

opening of no less than 5 mm.

Fixing the oven:

( FUS 100-40 W

FUS 100-40 X )
