Preparing Your Radio For Use

CHP950HD Double earpiece defender headset with boom mic and in line PTT for hard hat & VOX*

CHP950D Double earpiece headband defender headset with boom mic and in line PTT & VOX*

CHP950BT Bluetooth double earpiece headband defender headset with boom mic and ear cup PTT

* VOX = Voice Operated Transmit (hands free operation)

Antenna Options

CXW640 Antenna adapter for external aerial

CAT20 Helical antenna VHF

CAT80 Whip antenna UHF

CAT20S Stubby antenna VHF

CAT80S Stubby antenna UHF

For complete up to date list of optional

accessories visit www.entel.co.uk

CAT10S-78 78MHz compressed antenna

CAT10S-85 85MHz compressed antenna

CAT10S 66-88MHz uncut compressed antenna

CAT700-40 30-50MHz antenna

Bluetooth option board in radio is required to use Bluetooth audio accessories.

Attaching / Removing the Battery Pack

1 To attach, locate the pegs on the bottom of the

battery and place into the slots on the radio. Then

press the top of the battery against the radio. Secure

battery by tightening the screw clockwise by hand.

(Do not over tighten)

2 To remove, unscrew the locking screw anticlockwise

and pull the battery away from the top of the radio.

Attaching / Removing the Belt Clip

1 To attach, press the clip into the slot on the back

of the battery and slide up until you hear a “click”.

2 To remove, pull the tab (a) towards the belt clip.

Then slide the belt clip downwards (b).
