PRIME B550-PLUS specications summary
CPU
AMD Socket AM4 for 3
rd
Gen AMD Ryzen™ Processors*
*Refer to www.asus.com for CPU support list.
Chipset AMD B550 Chipset
Memory
3
rd
Gen AMD Ryzen™ Processors
4 x DIMM, Max. 128GB, DDR4 4400(O.C)/4000(O.C)/3866(O.C)/3600(O.C)/
3466(O.C.)/3200/3000/2800/2666/2400/2133 MHz, Un-buffered Memory*
Dual Channel Memory Architecture
*ECC Memory (ECC mode) support varies by CPU.
**Refer to www.asus.com for the Memory QVL (Qualied Vendors Lists).
Graphics
1 x DisplayPort 1.2
1 x HDMI
TM
2.1(4K@60HZ)
*Graphics specications may vary between CPU types.
Expansion Slots
3
rd
Gen AMD Ryzen™ Processors
1 x PCIe 4.0 x16 slot (supports x16 mode)
AMD B550 Chipset
1 x PCIe 3.0 x16 slot (supports x4 mode)*
3 x PCIe 3.0 x1 slots**
*Support PCIe bifurcation for RAID on CPU function.
** PCIE 3.0 X16_2 runs x2 mode when PCIEX1_2 or PCIEX1_3 is occupied.
Multi-GPU Support
Supports AMD 2-Way CrossFireX™ Technology
Storage
Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports
3
rd
Gen AMD Ryzen™ Processors
M.2_1 slot (Key M), type 2242/2260/2280/22110
(supports PCIe 4.0 x4 & SATA modes)
AMD B550 Chipset
M.2_2 slot (Key M), type 2242/2260/2280/22110
(supports PCIe 3.0 x4 & SATA modes)*
6 x SATA 6Gb/s ports
Support Raid 0, 1, 10
* M2_2 shares bandwidth with SATA6G_56. When M.2_2 is populated, SATA6G_56
will be disabled.
(continued on the next page)
Package contents
Check your motherboard package for the following items.
Motherboard
1 x PRIME B550-PLUS motherboard
Cables
2 x SATA 6Gb/s cables
Miscellaneous
1 x I/O Shield
1 x M.2 SSD screw package
Application DVD
1 x Support DVD
Documentation
1 x User manual
If any of the above items is damaged or missing, contact your retailer.
