Asus PRIME X299-DELUXE II [10/108] Prime x299 deluxe ii specifications summary
![Asus PRIME X299-DELUXE II [10/108] Prime x299 deluxe ii specifications summary](/views2/1769272/page10/bga.png)
x
Storage
Intel
®
Core™ X-Series Processors support with Intel
®
Rapid
Storage Enterprise Technology
- 1 x M.2_3 Socket 3 with M key, type 2242/2260/2280/22110
storage devices support (supports PCIE 3.0 x4 mode only)
Intel
®
X299 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage
Technology support
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280/22110
storage devices support (both SATA & PCIE 3.0 x4 mode)
- 1 x M.2_2 Socket 3 with vertical M Key, type
2242/2260/2280/22110 (supports PCIE 3.0 x4 mode only)
- 8 x SATA 6.0 Gb/s ports*
- Ready for Intel
®
Optane™ Memory
* The SATA6G_7 shares bandwidth with PCIEX1_2. SATA6G_5 &
SATA6G_6 shares bandwidth with PCIEX16_3 when using 28-lane
CPUs.
OLED
2-inch OLED panel for system information
ASUS LiveDash Utility
Audio
Realtek
®
S1220A 8-channel high definition audio CODEC
featuring Crystal Sound 3
- Impedance sense for front and rear headphone outputs
- High quality 120dB SNR stereo playback output and 113dB SNR
recording input
- Internal audio Amplier to enhance the highest quality sound for
headphone and speakers
- Power pre-regulator reduces power input noise to ensure consistent
performance
- Unique de-pop circuit to reduce start-up popping noise to audio
outputs
- Separate layer for left and right track, ensuring both sound deliver
equal quality
- Audio shielding ensures precise analog/digital separation and
greatly reduced multi-lateral interference
- Premium Japan-made audio capacitors
- Supports up to 32-Bit/192kHz playback*
- Supports jack-detection, multi-streaming, front panel jack-retasking
(MIC)
- Optical S/PDIF out port at back I/O
Audio Features:
- DTS
®
Headphone:X™
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio. 32-Bit/192kHz is only available under Windows
®
10.
Thunderbolt™ 3
2 x Intel
®
Thunderbolt™ 3 ports (USB Type-C™)
- Data transfer rate of up to 40 Gbps in Thunderbolt™ 3 devices, up
to 10 Gbps in USB 3.1 Gen 2 devices
- Up to 5V/3A, 15W charging support
- Daisy-chain up to 6 Thunderbolt™ 3 devices
(continued on the next page)
PRIME X299-DELUXE II specifications summary
