ROG CROSSHAIR VIII DARK HERO
specifications summary
Internal I/O connectors
Miscellaneous
2 x AURA Addressable Gen 2 header(s)
2 x AURA RGB header(s)
1 x Front Panel Audio header (AAFP)
1 x LN2 Mode jumper
1 x Reset button
1 x ReTry button
1 x Safe Boot button
1 x Slow Mode switch
1 x Speaker header
1 x TPM header (14-1pin)
1 x Start button
1 x 10-1 pin System Panel header
1 x Thermal Sensor header
Special Features
Extreme OC Kit
- LN2 Mode
- ReTry button
- Safe boot button
- Start button
- Slow Mode
Extreme Engine Digi+
- 10K Black Metallic Capacitors
- TI CSD95410RRB Power Stage (90A)
- MicroFine Alloy Choke
ASUS Q-Design
- ASUS Q-Code
- ASUS Q-Connector
- ASUS Q-DIMM
- ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device
[yellow green])
- ASUS Q-Slot
ASUS Thermal Solution
- Aluminum M.2 heatsink
- Chipset passive cooling solution
ASUS EZ DIY
- BIOS FlashBack™ button
- Clear CMOS button
- Procool II
- Pre-mounted I/O shield
- SafeSlot
AURA Sync
- AURA RGB header(s)
- Addressable Gen 2 RGB header(s)
(continued on the next page)
