viii
ROG CROSSHAIR VIII DARK HERO
specifications summary
Storage
AMD Ryzen™ 5000 and 3000 Series Desktop Processors
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 (PCIe 4.0 x4 and
SATA modes) storage devices support
AMD Ryzen™ 4000, 3000, 2000 Series and 2000 G-Series Desktop
Processors
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 (PCIe 3.0 x4 and
SATA modes) storage devices support
AMD X570 chipset
- 1 x M.2 Socket 3 with M Key, type 2242/2260/2280/22110(PCIe 4.0 x4
and SATA modes) storage devices support
- 8 x SATA 6Gb/s ports
- Support Raid 0, 1, 10
Ethernet
1 x Realtek RTL8125-CG 2.5Gb Ethernet
1 x Intel
®
I211-AT 1Gb Ethernet
ASUS LANGuard
Wireless & Bluetooth
Intel
®
Wi-Fi 6 AX200
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO
Supports up to 2.4Gbps max data rate
Supports 2.4/5GHz Dual-Band
Supports channel bandwidth: HT20/HT40/HT80/HT160
Supports PCIe interface
Bluetooth v5.1*
* Bluetooth 5.1 function will be ready in Windows 10 build 19041 or later.
USB
AMD Ryzen™ 5000, 4000 G-Series and 3000 Series Desktop
Processors
- 4 x USB 3.2 Gen 2 ports (4 ports at back panel, Type-A [red])
AMD Ryzen™ 3000, 2000 Series and 2000 G-Series Desktop
Processors
- 4 x USB 3.2 Gen 1 ports (4 ports at back panel, Type-A [red])
AMD X570 chipset
- 1 x USB 3.2 Gen 2 front panel connector
- 4 x USB 3.2 Gen 2 ports (4 ports at back panel, 3 x Type-A [red], 1 x
USB Type-C
®
)
- 6 x USB 3.2 Gen 1 ports (4 ports at back panel [blue], 2 ports at front
panel)
- 4 x USB 2.0 ports at front panel
Audio
ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC
S1220
- Impedance sense for front and rear headphone outputs
- Supports: Jack-detection, Multi-streaming, Front Panel Jack-
retasking
- High quality 120 dB SNR stereo playback output and 113 dB SNR
recording input
- Supports up to 32-Bit/192 kHz playback*
(continued on the next page)
