ROG STRIX B450-F GAMING II BIOS Manual
31
6.3 CPU Configuration
The items in this menu show the CPU-related information that the BIOS automatically
detects.
The items in this menu may vary based on the CPU installed.
PSS Support
This item allows you enable or disable the generation of ACPI_PPC, _PSS, and _PCT
objects.
Configuration options: [Disabled] [Enabled] [Auto]
NX Mode
This item allows you enable or disable no-execute page protection function.
Configuration options: [Disabled] [Enabled]
SVM Mode
This item allows you enable or disable CPU Virtualization.
Configuration options: [Disabled] [Enabled]
