x
(continued on the next page)
ROG STRIX X299-E GAMING II specifications summary
Storage
Intel
®
Core™ X-Series Processors support with Intel
®
Virtual
RAID on CPU (VROC)
- 2 x M.2 Socket 3 with M key, type 2242/2260/2280/22110 storage
devices support (PCIe 3.0 x4 mode)*
Intel
®
X299 Chipset supports with Intel
®
Rapid Storage
Technology (RAID 0, 1, 5, 10)
- 8 x SATA 6Gb/s ports
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280/22110
storage devices support (both SATA & PCIe 3.0 x4 modes)
- Intel
®
Optane Memory ready
* M.2_2 and M.2_3 are supported by 48-Lane CPU and 44-Lane CPU
(Intel
®
Core™ i7 9000 X-Series CPU or above).
LAN
Intel
®
I219-V Gigabit LAN
Realtek
®
RTL8125-CG 2.5G LAN
Anti-surge LANGuard
ROG GameFirst Technology
Wireless & Bluetooth
Intel
®
Wi-Fi 6 AX200
2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) with MU-MIMO supports dual
frequency band 2.4/5GHz
Supports channel bandwidth: HT20/HT40/HT80/HT160
Up to 2.4 Gbps transfer speed
Bluetooth v5.0
Audio
ROG SupremeFX S1220A 8-Channel High Definition Audio
CODEC
- Supports up to 32-Bit/192kHz playback*
- Impedance sense for front and rear headphone outputs
- High quality 120dB SNR stereo playback output and 113dB SNR
recording input
- SupremeFX Shielding Technology
- Dual Headphone Ampliers
- Jack-detection, Multi-streaming, and Front Panel Jack-retasking
- Optical S/PDIF out port at back panel
Audio Features:
- Gold-plated jacks
- Sonic Studio III + Sonic Studio Virtual Mixer
- Sonic Radar III
- DTS
®
Sound Unbound
* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported for
8-Channel audio.
