xi
ROG STRIX X299-E GAMING II specifications summary
(continued on the next page)
USB
Intel
®
X299 Chipset-
- 6 x USB 3.2 Gen 1 ports (2 ports at back panel [blue], 4 ports at
mid-board)
- 8 x USB 2.0 ports (4 ports at back panel, 4 ports at mid-board)
ASMedia
®
USB 3.2 Gen 2 controllers-
- 4 x USB 3.2 Gen 2 ports (3 x Type-A [red] and 1 x Type-C™ port
at back panel)
- 1 x USB 3.2 Gen 2 front panel connector*
* The USB 3.2 Gen 2 front panel connector shares bandwidth with
PCIEX1 slot.
ROG Exclusive Features
ROG RAMCache III
ROG GameFirst V
ROG CPU-Z
ROG Overwolf
Sonic Studio III + Sonic Studio Virtual Mixer
Sonic Radar III
FlexKey
Special Features
Performance Optimization*
5-Way Optimization
- Whole system optimization with a single click! Perfectly
consolidates better CPU performance, power saving, digital
power control, system cooling and app usages.
Digi+VRM
EPU
- EPU
TPU
- Auto Tuning
Fan Xpert 4 featuring Fan Auto Tuning function and
multiple thermistors selection for optimized system cooling
control
Turbo Core App (6-core or above CPU)
* Only available on Intel
®
Core™ X-Series Processors
LiveDash OLED
AI Overclocking
AURA:
- Aura Lighting Control
- Aura RGB Strip Headers
- Aura Addressable Gen 2 Headers
ASUS EZ DIY
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 3
- EZ Tuning Wizard
