DONOTconnecta1394cabletotheUSBconnectors.Doingsowilldamagethe

motherboard!

TheUSB2.0moduleispurchasedseparately.

6. USB 2.0 connector (10-1 pin USB910)

ThisconnectorisforUSB2.0ports.ConnecttheUSBmodulecabletothese

connectors,theninstallthemoduletoaslotopeningatthebackofthesystemchassis.

ThisUSBconnectorcomplieswithUSB2.0specicationthatsupportsupto480Mb/s

connectionspeed.

7. LED connector (13-pin LED1_CON1)

ThisconnectorisforconnectingtheLEDcardlocatedunderthemotherboardbackIO

cover.
