ROG STRIX H370-F GAMING specifications summary
CPU
Intel
®
Socket 1151 for 8th Generation Intel
®
Core™ Processor**
Supports 14nm CPU
Supports Intel
®
Turbo Boost Technology 2.0*
* The support of these features depends on the CPU types.
** Refer to www.asus.com for Intel
®
CPU support list.
Chipset
Intel
®
H370 Chipset
Memory
4 x DIMM, max. 64GB DDR4 2666 / 2400 / 2133 MHz Non-ECC, Un-
buffered Memory
Dual channel memory architecture
Supports Intel
®
Extreme Memory Prole (XMP)*
* The maximum memory frequency supported varies by processor. Please refer to
Memory QVL(Qualified Vendors List) for details.
Graphics
Integrated Graphics Processor- Intel
®
HD Graphics support
Multi-VGA output support: DisplayPort/HDMI/DVI-D ports
- Supports DisplayPort* with max. resolution 4096 x 2304@60Hz
- Supports HDMI with max. resolution 4096 x 2160@24Hz / 2560 x
1600@60Hz
- Supports DVI-D with max. resolution 1920 x 1200 @ 60 Hz
Maximum shared memory of 1024MB
* DP 1.2 Multi-Stream Transport compliant, supports DP 1.2 monitor daisy chain
up to 3 displays
Multi-GPU
support
Supports AMD 2-Way CrossFireX Technology
Expansion slots
8th Generation Intel
®
Core™ Processor
1 x PCIe 3.0/2.0 x16 slot (supports x16)
Intel
®
H370 Chipset
1 x PCIe 3.0/2.0 x16 slot (max at x4 mode)
4 x PCIe 3.0/2.0 x1 slots
Storage
Intel
®
H370 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage
Technology support
- 1 x M.2_1 Socket 3 with M key, type 2242/2260/2280 storage devices
support (SATA & PCIE 3.0 x 2 mode)*
- 1 x M.2_2 Socket 3 with M key, type 2242/2260/2280 storage devices
support (PCIE 3.0 x 4 mode)
- 6 x SATA 6Gb/s ports
- Intel
®
Optane Memory Ready**
* The M.2_1 socket shares bandwidth with SATA6G_2 port when using M.2 SATA
mode device. Adjust BIOS settings to use X2 mode (PCIE only).
** Intel
®
Optane™ Technology only supported when using 8th Generation Intel
®
Processors. Before using Intel
®
Optane™ memory modules, ensure that you
have updated your motherboard drivers and BIOS to the latest version from
ASUS support website.
(continued on the next page)
